TYPHON TERROR XVII PRO 3800 lb Mini Excavator, Kubota D902 Diesel, Hydraulic Thumb, Pilot Controls, 14kN Dig Force

Introducing the latest TYPHON TERROR XVII PRO with an operating weight of 3,800 lb, this mini excavator delivers the stability, power, and durability required for demanding jobs. With upgraded protection, refined hydraulics, and enhanced operator comfort, this unit is made to tackle tough conditions with confidence. Reinforced components and hydraulic protection assist maximize uptime, while the redesigned operator station keeps you comfortable and productive throughout the day.

1. EPA-Certified Kubota Engine

Kubota D902 diesel engine: Producing 15.8 HP at 2200 RPM and reaching 20.4 HP at 3600 RPM, the Japanese-built Kubota D902 is a compact vertical 3-cylinder, 4-cycle diesel engine crafted for smooth power delivery, outstanding fuel productivity, and lasting durability. Trusted worldwide for its reliability.

EPA-certified output: Made to meet strict EPA emissions standards, supporting you to work confidently while maintaining clean and productive performance.

Extended runtime capacity: With a generous 4.76-gallon hydraulic oil reservoir and a 3.17-gallon fuel tank, This machine is made to stay productive longer, reducing downtime and helping keep dependable performance throughout demanding workdays.

2. Advanced Hydraulic System

High-pressure hydraulic system: Operating at 2,611 PSI (2,610.68 PSI), the hydraulic system delivers strong and consistent power for digging and demanding attachment applications.

Precision pilot controls: With a 1.82 GPM pilot flow, the system delivers smooth, responsive, and precise operation for grading, trenching, and detailed work.

Dual auxiliary hydraulic circuits: built to support superior versatility, the double-side auxiliary throttle valves deliver uninterrupted hydraulic flow to powered attachments and the hydraulic thumb simultaneously. Whether drilling with an auger, breaking concrete, or handling materials, this 3,800lbs mini excavator keeps you productive without the need for setup changes.

Integrated hydraulic oil cooler: Assists prevent overheating during continuous operation, keeps dependable operation in hot climates, and extends hydraulic system life.

3. Superior Mobility & Reach

Precision offset boom swing: Providing 45° left swing and 55° right swing, This offset boom allows precise digging around walls, foundations, and restricted areas with minimal repositioning.

Smooth full 360° swing: Combined with a high-output 6.07 GPM main hydraulic flow, the continuously rotating upper structure motor provides effortless positioning, faster cycle times, and outstanding versatility for digging, loading, and load handling from virtually any angle.

Confident travel speed: Traveling up to 1.30 MPH, This machine moves smoothly and confidently around the jobsite.

Sure-Grip rubber tracks: Built with wide 9.06-inch tracks, the undercarriage delivers excellent flotation, superior traction, and dependable stability across muddy, soft, and uneven terrain.

4. Exceptional Digging output

High-output 3,147 lbf digging force: brings the breakout power needed to penetrate hard soil, compacted ground, and roots with controlled performance, helping complete demanding tasks more efficiently.

All-in-One work package: Fitted with a 16.54-inch bucket, 1.41 cu ft bucket capacity, 86.50-inch maximum digging depth, standard dozer blade, and hydraulic thumb clip, This TERROR XVII PRO is ready to dig, grade, grab, and clean up with exceptional versatility while moving more material in fewer passes.

5. Premium-Modern Design & Operator Comfort

Bold Yellow Design: A striking, modern yellow exterior gives The unit an aggressive, high-visibility look that commands attention on any jobsite.

Ergonomic operator seat: With a premium headrest and armrests to deliver exceptional assist and comfort during extended working hours.

Spacious operator station:with an interior height of 41.34 inches and width of 20.08 inches, This roomy cabin assists cut fatigue and keeps operators productive throughout long shifts.

Centrally located service access: Both This diesel fuel tank and hydraulic oil reservoir are conveniently positioned in one location, supporting quick refilling, easier servicing, and less downtime throughout the workday.

Armored hydraulic hoses and protected valves: Commercial-grade armored hoses and shielded hydraulic valves are made to resist abrasion, impacts, and harsh working conditions. Together, they assist prevent leaks, minimize downtime, and maximize long-term reliability in demanding applications.

The TYPHON TERROR XVII PRO combines trusted Kubota power, a professional-grade full hydraulic control system, exceptional maneuverability, high-output digging capability, and operator-focused comfort into one dependable machine. Whether you’re trenching, grading, load handling, or tackling demanding construction jobs, it’s made to provide the performance, reliability, and versatility professionals demand.

Don’t settle built to support less when real power is within reach.

Why Choose TYPHON MACHINERY?

Customer Assurance: We deliver responsive service and dependable parts assist to assist keep your machine runs smoothly for years.

output You Can Trust: Every TYPHON excavator is built with premium components for durability, performance, and operator safety.

Global Reliability: Trusted by contractors and builders across This USA and beyond for providing consistent quality and productivity.

Your construction jobs will reach new heights with the TYPHON TERROR XVII Pro Mini Excavator. Compact, tough, and productive, this trench digger machine is your ideal companion for successful projects at a mini scale. Trust TYPHON Machinery for reliability, toughness, and performance that surpass expectations. Elevate your construction game with the TYPHON TERROR XVII Pro – The ultimate solution for all your excavation needs!
